door switch

Lift Features:

• Double-acting gas lift
• Mounting center distance: 610mm
• Lift stroke: 250mm
• Ball joint mounting: Ø 8mm (x2)
• Cylinder force : 550N
• Not suitable for models with 2 cylinders

Suitable for:

• R5 Alpine (R1223)
• R5 Alpine Turbo (R122B): From the beginning of the series to no. 38156
• R5 Turbo 2 (8220): From no. 2001 to No. 3346
• OE Renault Ref: 6001010706 / 6001011831 / 7701349615

The struts must be mounted with the rod down, with the trunk or hood closed.

In most cases, it is not possible to compress the strut by hand due to its force.

• Length: 36.5cm
• Male/Female Connection: Ø 3/8"-24UN
• Original Renault OE Reference: 7701348758

Please note this hose cannot replace the original oil hoses, use only to carry out an adaptable assembly using a connector and a new radiator.

Material: Black synthetic braid

Maximum operating pressure 35 bar and burst pressure 138 bar

The central unit is connected as follows:

• The 12V power supply (+ battery) wire on the "X" or "+" terminal
• The Switch or stalk control wire on the "L" or "Z" terminal
• The repeater indicator light wire (LED) on the "P" terminal

Indoor/outdoor alu-cardboard sheath
